COMP CAMS XTREME MARINE CAMSHAFT 242/248@50 .566/566" CHEV BIG BLOCK CO01-456-8

Item Description

COMP CAMS XTREME MARINE CAMSHAFT 242/248@50 .566/566" CHEV BIG BLOCK CO01-456-8
These Xtreme Marine camshafts from COMP Cams are designed to take advantage of the newest developments in camshaft design. Their aggressive lobe design produces better throttle response and top-end horsepower than other cams with the same duration at .050 in., while delivering increased engine vacuum. These cams are available for everything from pleasure boats to race applications, so you can always have Xtreme performance on the water.
Specs:
Application: Chev Big Block Gen VI 454 C.I.D
Cam Style:Hydraulic roller tappet
Basic Operating RPM Range:2,800-6,200
Intake Duration at 050 inch Lif242
Exhaust Duration at 050 inch Lif248
Duration at 050 inch Lif242 int./248 exh.
Advertised Intake Duration:296
Advertised Exhaust Duration:302
Advertised Duration:296 int./302 exh.
Intake Valve Lift with Factory Rocker Arm Ratio:0.566 in.
Exhaust Valve Lift with Factory Rocker Arm Ratio:0.566 in.
Valve Lift with Factory Rocker Arm Ratio:0.566 int./0.566 exh.
Lobe Separation (degrees):112
Camshaft Gear Attachmen3-bolt
Computer-Controlled Compatible:No
Grind Number:CBVI XM296HR-12
Valve Springs Required:Yes
Quantity:Sold individually.


Manufacturer Information

  • Manufacturer: COMP Cams
  • Manufacturer Part Number:
  • UPC:
  • Colour:
  • Additional Information:
  • Please Note: Images are for representation only and may differ than the actual product - please contact us if you require an exact photo
