MSD Ignition MSD2360 suit Ford 289 302 Bronze Gear Pro Billet Cam Sync Distributor

Are you running an aftermarket fuel injection system and looking for a top-notch distributor that actually works? If so, these MSD Pro-Billet Cam Sync distributors are just what you need. They're designed to work with EFI management systems that fire the fuel injectors in the same order as the engine's firing order. They require a sync signal to know when the number one cylinder is firing and feature an adjustable sync pickup so you can set it to match your ECU's requirements (up to 60 degrees BTDC). This sync pickup uses a powerful, rare-earth magnet for strong trigger signals, and the wiring is routed through a weathertight connector for a positive-locking sealed connection. Each distributor housing is CNC-machined from billet 6061-T6 aluminum, creating a strong, precise housing. The rotor features thick vanes to stir up the air and is injection-molded from Rynite for high dielectric strength. A 0.500 in. polished steel shaft spins the rotor and is guided by a sealed ball bearing at the top and an extra-long sintered bushing at the bottom for added stability. These distributors are ready to drop in your race engine, from the bronze gear to the brass terminals of the cap. Chevrolet models have an adjustable slip collar that allows you to accurately set the distributor's installation depth in the engine. An MSD crank trigger, ignition control, and MSD 6, 7, 8, or 10 Series ignition must be used.

Trigger Style: Hall effect

Advance Type: Computer-controlled

Cap Style: Male/HEI

Slip Collar: No

Gear Material: Bronze

Ignition Box Required: Yes

Distributor Gear Rotation: Standard

Distributor Cap Color: Black

Housing Material: Billet aluminum

Housing Finish: Polished

Marine Use: No

Quantity: Sold individually.

Notes: Includes adjustable rotor, adjustable cam sync, as well as a magnetic pickup. Must be used with MSD 6, 7, or 8 Series ignition.
