Proflow PFETBP4150S Fuel Injection Conversion Plate Kit Series II 4150 & 4500 Billet Aluminium Silver Universal

Proflow’s EFI conversion Fuel Injection Plate is an innovative way to convert your engine to EFI without needing to spend thousands of dollars.

Proflow’s Fuel Injection Plate eliminates the need to replace or modify your non-EFI intake manifold, providing it has a 4150 or 4500 bolt pattern. The Fuel Injection Plate provides a place for injectors and fuel rails to be mounted between your throttle body and intake manifold.

This plate allows you to securely mount up to eight 48mm lenth, 14mm OD injectors. If less than 8 injectors are required, injector blanks will be available.

What’s in the box?

• 1 x Fuel Injection Plate.
• 2 x Fuel Rails.
• 4 x Fuel Rail mounting shafts.
• 4 x Grub Screws to fasten shafts.

A management system compatible with the injectors is necessary to provide tunability. This is a great set up with one of Proflow’s Quad Throttle bodies and Air Cleaners. For race applications it could also be used with one of Proflow’s fabricated Throttle Body Necks. Sinlge plane intake manifolds are recommended.

Note: When used with a Proflow Quad Throttle Body the vacuum ports will need to be blocked off as the protruding fittings will not clear the Injector Plate’s fuel rails. Alternatively, a spacer between the throttle body and Injector Plate will allow the fittings to clear the fuel rail.
