Aeroflow AF95-0302 SBF 173CC Aluminium Heads Bare60CC Chambers 2.02"/1.60"

SBF 173CC Aluminium Heads Bare60CC Chambers 2.02"/1.60"

1 3
Aeroflow Performance
Aeroflow Performance Part No. AF95-0302
$1,416.95 AUD
$1,416.95 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

AF95-0302

Expert Advice Talk to real engine builders
Fast Dispatch Australia Wide Shipping
Family Owned Trusted since 1988
Secure Checkout Safe & Encrypted Payments
Availability: In-Store - Ready to Ship*
✔ Secure Checkout
✔ Easy Returns
✔ Need Help? Call (02) 6025 5666
View full details

Product Information

Aeroflow's Small block Ford Windsor cylinder heads are designed for entry-level street performance engines and ideal for operating in the idle to 6500 rpm range. Made from A356 aluminium castings. These complete heads include larger-than-stock 1.46" (37 mm) diameter valve spring with damper to handle up to 0.575" (14.61mm) maximum valve lift. Recommended spark plugs are 14mm x 3/4" reach with flat gasket seat.

Head Specs:
Chamber volume: 60cc Chamber
Intake port volume: 173cc
Intake valve size: 2.02"
Exhaust valve size: 1.60"
Valve spring diameter: Single spring with damper 1.460" (37mm)
Spring installed height: 1.73" @ 145lbs
Maximum valve lift: 0.575" (14.61mm) @ 315lbs
Rocker stud diameter: 7/16"
Pushrod diameter: 5/16" (width of slot in guide plate)
Spark plug style: Angled

Flow Chart cfm @ H2O
  .100" .200" .300" .400" .500" .600"
2.020 Intake 73 129 184 219 246 256
1.600 Exhaust 58 105 142 164 171 174


Product Information

Aeroflow's Small block Ford Windsor cylinder heads are designed for entry-level street performance engines and ideal for operating in the idle to 6500 rpm range. Made from A356 aluminium castings. These complete heads include larger-than-stock 1.46" (37 mm) diameter valve spring with damper to handle up to 0.575" (14.61mm) maximum valve lift. Recommended spark plugs are 14mm x 3/4" reach with flat gasket seat.

Head Specs:
Chamber volume: 60cc Chamber
Intake port volume: 173cc
Intake valve size: 2.02"
Exhaust valve size: 1.60"
Valve spring diameter: Single spring with damper 1.460" (37mm)
Spring installed height: 1.73" @ 145lbs
Maximum valve lift: 0.575" (14.61mm) @ 315lbs
Rocker stud diameter: 7/16"
Pushrod diameter: 5/16" (width of slot in guide plate)
Spark plug style: Angled

Flow Chart cfm @ H2O
  .100" .200" .300" .400" .500" .600"
2.020 Intake 73 129 184 219 246 256
1.600 Exhaust 58 105 142 164 171 174


Technical Information

Features

Genuine performance part backed by Engine Master Australia.

Specifications
Manufacturer
Aeroflow Performance Products
MPN
Not provided
UPC
9.33721E+12
Our Part Number
AF95-0302
Cylinder head configuration: Bare
Fitment

Confirm compatibility with our team before ordering when your application is not listed.

Brand

Aeroflow Performance

Aeroflow Performance Products are available from Engine Master Australia, supported by practical product knowledge and Australia-wide delivery.

Read more about Aeroflow Performance →
