AFR - Air Flow Research

Air Flow Research AFR1383 Airflow Research 195cc Ford SB Renegade Competition Cylinder Heads

Air Flow Research AFR1383 Airflow Research 195cc Ford SB Renegade Competition Cylinder Heads

AFR1383
$4,494.60 AUD
$4,494.60 AUD
Sale Sold out
Tax included. Shipping calculated at checkout.
Are you building your own personal street/strip weapon? These AFR 195cc SBF Competition cylinder heads are designed for you. To make big horsepower, you need heads that can flow large amounts of air--that's where AFR, the masters of airflow come in. These heads feature a 195cc intake port, 70cc exhaust ports, and your choice of 58 or 72cc combustion chambers to complement your engine. To get the fuel and air in and out efficiently, AFR uses lightweight 8mm 2.050 intake valves and 1.600 exhaust valves. The thick deck makes these heads ideal for nitrous or blower applications with the optional nitrous/blower exhaust port. These heads are most at home on performance engines operating primarily between 2,000 and 7,000 rpm. Dominate the street and strip with the help of AFR and these 195cc SBF Competition cylinder heads.

  • Cylinder Head Style:Assembled
  • Cylinder Head Material:Aluminum
  • Cylinder Head Finish:Natural
  • Combustion Chamber Volume (cc):72
  • CNC-Machined Combustion Chamber:Yes
  • Intake Runner Volume (cc):195cc
  • Exhaust Runner Volume (cc):70cc
  • CNC-Machined Intake Runner:Yes
  • CNC-Machined Exhaust Runner:Yes
  • Combustion Chamber Style:Heart
  • Intake Port Shape:Rectangular
  • Intake Port Location:Standard
  • Exhaust Port Shape:Square
  • Exhaust Port Location:Standard
  • Spark Plug Style:Angle
  • Intake Valves Included:Yes
  • Intake Valve Diameter (in):2.020 in.
  • Exhaust Valves Included:Yes
  • Exhaust Valve Diameter (in):1.600 in.
  • Valve Springs Included:Yes
  • Maximum Valve Lift (in):0.600 in.
  • Outside Diameter of Outer Spring (in):1.290 in.
  • Damper Spring Included:Yes
  • Number of Springs Per Valve:Dual
  • Retainers Included:Yes
  • Retainer Material:Chromoly steel
  • Locks Included:Yes
  • Lock Style:7 degree
  • Valve Stem Seals Included:Yes
  • Rocker Arm Studs Included:Yes
  • Rocker Arm Nut Thread Size:3/8-24 in.
  • Rocker Arms Included:No
  • Rocker Arm Nuts Included:Yes
  • Guideplates Included:Yes
  • Guideplate Pushrod Size:5/16 in.
  • Valve Cover Mounting Style:Perimeter bolt
  • Accessory Bolt Holes Drilled:Yes
  • Intake Valve Angle:20
  • Exhaust Valve Angle:20
  • Valve Guides Included:Yes
  • Valve Guide Material:Bronze
  • Valve Seats Machined:Yes
  • Valve Seat Machine Style:3-angle
  • Valve Seat Material:Ductile iron
  • Steam Holes Drilled:No
  • Oiling Style:Through pushrod
  • Machined for O-Ring:No
  • Heat Crossover:No
  • Quantity:Sold as a pair.
  • Notes:Competition package. CNC bowl blend, intake and exhaust ports are fully CNC ported. No EGR or air pump accessory holes.

Manufacturer Part Number:
