BluePrint PS4541CTC1 Chev BB 454 CI ProSeries Stroker Crate Engine Dressed w/ Carb 563HP

BluePrint Engines Pro Series Chevy 454 C.I.D. 563 HP Dressed Long Block Crate Engines

For those wanting maximum horsepower and durability that's pretty much ready to go, BluePrint Engines Pro Series Chevy 454 c.i.d. 563 hp dressed long block crate engines are right for you. In addition, every BluePrint engine is dyno-tested to make sure they hit their target horsepower and torque.

Pro Series 454 Dressed Long Blocks Feature:

• Power Specs: 563 hp, 545 ft.-lb., compression ratio 10.0:1
• Block: BluePrint cast iron block with 4-bolt main
  • 4.250 in. bore
  • 2-piece rear main seal
  • Mechanical fuel pump provision
  • Passenger side dipstick
  • Drilled and tapped for clutch linkage
• Rotating Assembly: Forged crankshaft and connecting rods
• Pistons: Forged pistons with rings
• Balance: Internal front/internal rear balanced rotating assembly
• Cylinder Heads: BluePrint aluminum cylinder heads
  • 64cc chamber
  • 2.08 in. intake / 1.60 in. exhaust valves
  • 220cc intake / 67cc exhaust runners
• Camshaft: Hydraulic roller cam
  • .638 intake / .622 exhaust lift
  • 251 intake / 259 exhaust duration @ .050
  • 114 degree lobe separation
• Included Components: Valve covers, oil pan, and timing cover
• Harmonic Balancer
• Distributor: MSD Pro billet distributor
• Carburetor: 950 cfm carburetor
• Intake Manifold: Aluminum intake manifold

Select BluePrint Engines are imported to order via airfreight, with delivery times typically ranging from 1 to 15 days. For an accurate ETA on specific models, please don't hesitate to contact us.

• UPC: 00887753744807
• Crate Engine Family: Chevy Small Block
• Actual Engine Displacement: 7.4L/454
• Crate Engine Cylinder Head Material: Aluminum
• Engine Block Material: Cast iron
• Advertised Compression Ratio: 10.0:1
• Assembled: Yes
• Engine Balance: Internal
• Cam Style: Hydraulic roller, OE roller
• Rear Main Seal Style: 1-piece
• Intake Manifold Included: Yes
• Intake Manifold Style: Carbureted
• Cylinder Heads Included: Yes
• Carburetor Included: Yes
• Throttle Body Included: No
• Distributor Included: Yes
• Oil Pan Included: Yes
• Valve Covers Included: Yes
• Timing Cover Included: Yes
• Water Pump Included: No
• Harmonic Balancer Included: Yes
• Flexplate Included: No
• Flywheel Included: No
• Air Cleaner Included: No
• Spark Plugs Included: Yes
• Spark Plug Wires Included: Yes
• Computer Included: No
• Wiring Harness Included: No
• Supercharger Included: No
• Remanufactured: No
• Quantity: Sold individually
• Notes: Features a 4-bolt main block and a forged rotating assembly.
