COMP Cams 646-431-13 XFI AFM 212/224 D, 210/222 N Hydraulic Roller Cam for GM LS2/LS3 GEN IV
646-431-13 XFI AFM 212/224 D, 210/222 N Hydraulic Roller Cam for GM LS2/LS3 GEN IV
1
/
of
4
Sale
Sold out
Taxes included.
Shipping calculated at checkout.
SKU:CO646-431-13
Expert Advice
Talk to real engine builders
Fast Dispatch
Australia Wide Shipping
Family Owned
Trusted since 1988
Secure Checkout
Safe & Encrypted Payments
Quantity
✔ Secure Checkout
✔ Easy Returns
✔ Need Help? Call (02) 6025 5666
Contact us for ETA or alternative options
View full details
✔ Easy Returns
✔ Need Help? Call (02) 6025 5666
Product Information
XFI AFM 212/224 D, 210/222 N Hydraulic Roller Cam

Product Information
XFI AFM 212/224 D, 210/222 N Hydraulic Roller CamTechnical Information
Features +
Genuine performance part backed by Engine Master Australia.
Specifications +
- Manufacturer
- COMP Cams
- MPN
- Not provided
- UPC
- 036584238003
- Our Part Number
- CO646-431-13
C.A.R.B. Exempt for On-Road Vehicles?: No
C.A.R.B. Exemption Reason: N/A
C.A.R.B. E.O. Number: N/A
10602: 262AFM15
Camshaft Series: XFI AFM
Cam Type: Hydraulic Roller
Grind Number: 262AFM15
Basic Operating RPM Range: 1,600-6,300
Lobe Separation: 115
Lifters Included: No
Valve Springs Required: Yes
Assembly Lubricant Included: No
Camshaft Gear Attachment: 1-Bolt
Advertised Intake Duration Non-Deactivation Cylinders: 262
Advertised Exhaust Duration Non-Deactivation Cylinders: 274
Intake Duration at .050" Non-Deactivation Cylinders: 210
Exhaust Duration at .050" Non-Deactivation Cylinders: 222
Intake Valve Lift Deactivation Cylinders: 0.5
Exhaust Valve Lift Deactivation Cylinders: 0.5
Intake Valve Lift Non-Deactivation Cylinders: 0.5
Exhaust Valve Lift Non-Deactivation Cylinders: 0.5
AFM Delete Camshaft Core Prefix: 146-
Amazon ASIN: B0066ST5MO
C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
Camshaft Material: Billet Steel
California Proposition 65: WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov
Engine Family: GM LS2/LS3 GEN IV Single-Bolt w/ AFM and w/o VVT 8 Cylinder (2005-2014)
Lifter Type: Hydraulic Roller
Engine RPO Compatibility: LS4, L76, L77, LH6, LY5, LMG, LFA
Advertised Intake Duration Deactivation Cylinders: 275
Advertised Exhaust Duration Deactivation Cylinders: 286
Intake Duration at .050" Deactivation Cylinders: 212
Exhaust Duration at .050" Deactivation Cylinders: 224
C.A.R.B. Exemption Reason: N/A
C.A.R.B. E.O. Number: N/A
10602: 262AFM15
Camshaft Series: XFI AFM
Cam Type: Hydraulic Roller
Grind Number: 262AFM15
Basic Operating RPM Range: 1,600-6,300
Lobe Separation: 115
Lifters Included: No
Valve Springs Required: Yes
Assembly Lubricant Included: No
Camshaft Gear Attachment: 1-Bolt
Advertised Intake Duration Non-Deactivation Cylinders: 262
Advertised Exhaust Duration Non-Deactivation Cylinders: 274
Intake Duration at .050" Non-Deactivation Cylinders: 210
Exhaust Duration at .050" Non-Deactivation Cylinders: 222
Intake Valve Lift Deactivation Cylinders: 0.5
Exhaust Valve Lift Deactivation Cylinders: 0.5
Intake Valve Lift Non-Deactivation Cylinders: 0.5
Exhaust Valve Lift Non-Deactivation Cylinders: 0.5
AFM Delete Camshaft Core Prefix: 146-
Amazon ASIN: B0066ST5MO
C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
Camshaft Material: Billet Steel
California Proposition 65: WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov
Engine Family: GM LS2/LS3 GEN IV Single-Bolt w/ AFM and w/o VVT 8 Cylinder (2005-2014)
Lifter Type: Hydraulic Roller
Engine RPO Compatibility: LS4, L76, L77, LH6, LY5, LMG, LFA
Advertised Intake Duration Deactivation Cylinders: 275
Advertised Exhaust Duration Deactivation Cylinders: 286
Intake Duration at .050" Deactivation Cylinders: 212
Exhaust Duration at .050" Deactivation Cylinders: 224
Fitment +
Confirm compatibility with our team before ordering when your application is not listed.
Brand +
COMP Cams
COMP Cams develops performance camshafts and coordinated valvetrain components for a broad range of engine platforms. The range includes camshafts, lifters, valve springs, rocker systems, timing components and matched kits for street and competition builds.
