Bolt-On Aluminium Strut Wheel-E-Bars 44' for Use On 3' Axle Tubes 19-11/16' Center-To-Center Mounting
Product Information
Wheelstands may look spectacular but they can actually hurt performance. Although some front end lift is beneficial to weight transfer, excessive lift can hurt. When a car wheelstands upon initial launch, it uses up power that could propel the vehicle forward. This results in slower ET's. As tire technology and horsepower levels progressed over the years, racers experimented with different ways to combat the wheelstanding problem. Most of the original designs consisted of merely bars or leaf springs that were welded directly to the rear end housing, hoping that they would prevent the front of the car from rising too high. One of the major problems with these early designs is that they caused the rear tires to unload resulting in a loss of traction.
Competition Engineering recognized this problem long ago and developed a series of Wheel-E-Barsâ„¢ designed to limit and control big wheelstands without unloading the rear tires. We accomplish this by utilizing an axle housing mounted bracket that allows the Wheel-E-Barâ„¢ to react instantaneously with rear housing movement. As the rear housing rotates, the natural rubber wheels come in contact with the track. The shock of this contact is absorbed by both the lower aluminum struts and the coil spring upper struts which keep the tires from unloading. As the housing continues to rotate more and the front end begins to lift, the coil springs on the upper struts start to compress. The more that the springs are compressed, the more force they exert converts the rotational energy into forward motion, resulting in quicker ET's.
- Bolt-On design, no welding required.
- Lower aluminum flat spring design.
- Solid rubber wheel with oilless bronze bearing.
- Upper link available in chrome finish.
- For use on 3" dia. axle tubes.
- 44" overall length.
- 19-11/16" center to center mounting bracket distance.
- Includes all necessary mounting hardware.
- Chrome Plated.
