Toyota 2JZ & 2JZGTE Engines Forged H-Beam Conrods 5.590" Long.866" Pin for Eagle Specialty Products EACRS5590T3D

Toyota 2JZ & 2JZGTE Engines Forged H-Beam Conrods 5.590" Long.866" Pin for Eagle Specialty Products EACRS5590T3D

1 2
Eagle Specialty Products
Eagle Specialty Products Part No. EACRS5590T3D
$1,323.30 AUD
$1,323.30 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

EACRS5590T3D

Expert Advice Talk to real engine builders
Fast Dispatch Australia Wide Shipping
Family Owned Trusted since 1988
Secure Checkout Safe & Encrypted Payments
Availability: In-Store - Ready to Ship*
✔ Secure Checkout
✔ Easy Returns
✔ Need Help? Call (02) 6025 5666
View full details

Product Information

The Eagle ESP H-beam connecting rods are a 2-piece, forged, vacuum-degassed, 4340-certified steel construction that provides outstanding strength, while still weighing much less than stock rods. Each rod is multi-stage heat-treated, X-rayed, sonic-tested, magnafluxed, 100 percent machined and then shot-peened to stress-relieve the metal. The rods have precision cap alignment sleeves to positively locate each rod cap, silicon bronze bushings for floating pin models and are available in stroker models that allow additional cam-to-rod clearance for large stroke combinations

Product Information

The Eagle ESP H-beam connecting rods are a 2-piece, forged, vacuum-degassed, 4340-certified steel construction that provides outstanding strength, while still weighing much less than stock rods. Each rod is multi-stage heat-treated, X-rayed, sonic-tested, magnafluxed, 100 percent machined and then shot-peened to stress-relieve the metal. The rods have precision cap alignment sleeves to positively locate each rod cap, silicon bronze bushings for floating pin models and are available in stroker models that allow additional cam-to-rod clearance for large stroke combinations

Technical Information

Features

Genuine performance part backed by Engine Master Australia.

Specifications
Manufacturer
Eagle Specialty Products
MPN
Not provided
UPC
Not provided
Our Part Number
EACRS5590T3D
Connecting Rod Length Center to Center (in): 5.590 in
Connecting Rod Beam Style: H-beam
Connecting Rod Material: Forged 4340 steel
Connecting Rod Finish: Shot-peened
Wrist Pin Style: Floating
Clearanced for Stroker: No
Cap Retention Style: Cap screw
Connecting Rod Bolt Brand: ARP
Connecting Rod Bolt Diameter: 5/16 in
Connecting Rod Bolt Material: ARP2000 alloy
Fastener Yield Strength (psi): 200,000 psi
Connecting Rod Bolt Head Style: 12-point
Approximate Connecting Rod Weight (g): 590
Big End Bore Diameter (in): 2.1667 in
Pin End Bore Diameter: 22.000mm
Big End Width (in): 1.020 in
Pin End Width (in): 1.000 in
Advertised Horsepower Rating (hp): 750 hp
Advertised RP:
M Rating: 8,500 rpm
Weight Matched SeYes:
Remanufactured: No
Magnafluxed: Yes
Quantity: Sold as a set of 6
