J314411 Coyote 5.0L Modular Dish Top Forged Piston 3.630" Bore 3.650" Stroke 5.933" Rod Length -17.4Cc Dome Volume
SKU:JE-J314411
✔ Easy Returns
✔ Need Help? Call (02) 6025 5666
Product Information
Coyote 5.0L Modular
We have redesigned and expanded our Ford Modular product line! The new pistons utilize a dedicated Forged Side Relief (FSR) forging that was specifically designed for high horsepower Modular engines. In addition we have found ways to reduce weight and maintain the durability needed for both street and racing use. Lightweight and extremely durable, these pistons are machined for 1.0mm, 1.2mm, 2.8mm rings.
Includes:
- Pin #866-2250-15-51C (98g)
- Round Wire Locks (#866-063-MW)
- Accumula tor Grooves
- Offset Pin
Specifications :
- Part #: J314411
- Bore: 3.630"
- Oversize: STD
- Stroke: 3.650
- Rod Length: 5.933"
- Compression Height: 1.174"
- Compression Ratio with 57cc chamber volume: 8.5
- Dome Volume: -17.4cc
- Gram Weight:
- Footnote: Forced Induction
- Reconmended Ring Set: JG1008-3632
