120-9695 Dynapro 4 Spot Brake Caliper suit 13" x .380" Rotor
Wilwood Disc Brakes
Part No. WIL120-9695
Sale
Sold out
Taxes included.
Shipping calculated at checkout.
SKU:WIL120-9695
Expert Advice
Talk to real engine builders
Fast Dispatch
Australia Wide Shipping
Family Owned
Trusted since 1988
Secure Checkout
Safe & Encrypted Payments
Quantity
✔ Secure Checkout
✔ Easy Returns
✔ Need Help? Call (02) 6025 5666
Contact us for ETA or alternative options
View full details
✔ Easy Returns
✔ Need Help? Call (02) 6025 5666
Product Information
WILWOOD DYNAPRO 4 SPOT BRAKE CALIPER SUIT .380"X13" ROTOR WIL120-9695
| The DynaPro Lug Mount (DP) forged billet caliper represents the newest generation of calipers available as an upgrade or replacement for applications previously using the long-standing Dynalite model series. DP calipers combine pure race technology with several new exclusive Wilwood performance enhancements. A sleek profile with superior strength and a fully detail machined finish provide the performance and looks for competition or show. |
| The strength of the DynaPro is a combination of process and design. The DynaPro is stress-flow forged from premium grade billet. Stress-flow forging realigns the grain structure of the metal within the contour of the body design. This process produces a part with superior strength over parts simply machined from straight grained blocks of billet. The FEA generated body design incorporates a highly fortified radial transition that eliminates steps and shoulders between the piston housings and the bridges. Incorporating a radius in this critical area substantially increases resistance to deflection and caliper body separation under load. Structural deflection and volume displacement testing have proven the efficiency of this innovative design. Reductions in overall deflection, and the subsequent decreases in fluid volume displacement, translate to increased clamping efficiency with less pedal travel. The bottom line is a firm, responsive pedal with outstanding stopping power. |
| Caliper Series | Billet DynaPro |
| Piston Diameter (in) | 1.750 in. |
| Caliper Piston Quantity | Four |
| Rotor Thickness (in) | 0.380 in. |
| Caliper Material | Billet aluminum |
| Caliper Finish | Black Powdercoat |
| Caliper Logo | Wilwood |
| Parking Brake Provision | No |
| Fittings Included | Yes |
| Fitting Attachment 1 | Female threads |
| Thread Size | 1/8 in. NPT |
| Brake Pads Included | No |
| Brackets Included | No |
| Quantity | Sold individually. |
