260-10376 Compact Combination Master Cyl 1-1/8" Bore Remote Reservoir
Wilwood Disc Brakes
Part No. WIL260-10376
Regular price
$219.50 AUD
Regular price
Sale price
$219.50 AUD
Taxes included.
Shipping calculated at checkout.
SKU:WIL260-10376
Expert Advice
Talk to real engine builders
Fast Dispatch
Australia Wide Shipping
Family Owned
Trusted since 1988
Secure Checkout
Safe & Encrypted Payments
Quantity
Availability:
Ships in 1-3 Business Days*
✔ Secure Checkout
✔ Easy Returns
✔ Need Help? Call (02) 6025 5666
View full details
✔ Easy Returns
✔ Need Help? Call (02) 6025 5666
Product Information
WILWOOD COMPACT COMBINATION MASTER CYL 1-1/8" BORE REMOTE RESERVOIR WB 260-10376
Wilwood's compact combination master cylinders have been designed for limited space applications requiring the output capacity of a full size master cylinder. The ultra short 3.37" compact body provides 2.16" of additional clearance between the mounting flange and the fluid outlet compared to previous remote reservoir master cylinders. A full 1.12" of piston stroke meets or exceeds the stroke capacity of most full size cylinders. With 1/8" NPT fluid outlet port located at the top radius of the cylinder bore, reduces the chances for trapped air. The black E-Coated aluminium body resists corrosion and maintains a durable long lasting finish.Specs:
| Master Cylinder Material | Aluminum |
| Master Cylinder Finish | Black |
| Master Cylinder Bore Size | 1.125 in. |
| Bowl Design | Single |
| Mounting Hole Quantity | 2 holes |
| Mounting Flange Center to Center Distance (in) | 2.250 in. |
| Remote Reservoir | Yes |
| Reservoir Included | Yes |
| Reservoir Material | Plastic |
| Reservoir Finish | White |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Pushrod Included | Yes |
| Mounting Brackets Included | No |
| Hardware Included | No |
| Quantity | Sold individually. |
