Product Information

WILWOOD GS COMPACT INTERGRAL MASTER CYLINDER WB260-15098 BLACK 3/4" BORE

Product Information

WILWOOD GS COMPACT INTERGRAL MASTER CYLINDER WB260-15098 BLACK 3/4" BORE

Technical Information

Features

Wilwood's new GS Compact Integral Master Cylinders are an all new rebuildable design featuring a high pressure die cast aluminum body with a protective e-coat finish. Integral cylinders feature a positive seal internal bellows cap. Internally, a refined return spring and piston assembly assures positive pressure control along with a quick and complete release.
Newly tooled high pressure die-cast aluminum bodies with protective e-coat finish
Newly designed internal piston and return spring assembly assures a quick and positive release with extended service life
Fully rebuildable design
All twist-on caps used on the integral reservoir models include positive seal bellows gaskets
Remote reservoir models use 7/16-20 male union inlet fittings with aluminum sealing washers
High displacement capacity with full 1.25" stroke in all models
Use for brake or clutch
Direct mounting to Wilwood and all similar brand pedals using 2.25" bolt hole center mounting flanges

Specifications

Manufacturer: Wilwood Disc Brakes
MPN: Not provided
UPC: 8.89545E+11
Our Part Number: WIL260-15098

Master Cylinder Bore size (in): 3/4 in.
Master Cylinder Outlet Size (in): 3/8-24 in.
Master Cylinder Stroke (in): 1.25 in.
Master Cylinder Material: Cast aluminum
Master Cylinder Finish: Black
Quantity: Sold individually.
